Supermicro SuperServer 6029P-TRT – Server – rack-mountable 2U – 2-way – no CPU up to – RAM 0 GB – SATA – hot-swap 3.5″ bay(s) – no HDD – AST2500 – Gigabit Ethernet, 10 Gigabit Ethernet – monitor: none – black

Descripción Corta:

Product Description: Supermicro SuperServer 6029P-TRT – rack-mountable no CPU – 0 GB – no HDD
Type: Server – rack-mountable
Height (Rack Units): 2U
Server Scalability: 2-way
Processor: No CPU
Processor Socket: Socket P
RAM: 0 GB (installed) / 2 TB (max) – DDR4 SDRAM – ECC
Storage Controller: SATA (SATA 6Gb/s)
Server Storage Bays: Hot-swap 3.5″
Hard Drive: No HDD
Optical Storage: No optical drive
Graphics Controller: ASPEED AST2500
Networking: 1GbE, 10GbE
Power: AC 120/230 V (50 – 60 Hz)
Power Redundancy: Yes
Color: Black
Dimensions (WxDxH): 17.2 in x 25.5 in x 3.5 in
Weight: 35.49 lbs
Manufacturer Warranty: Limited warranty – parts – 1 year ¦ Limited warranty – labor – 3 years

Descripción Completa:

General:
Type: Server
Product Form Factor: Rack-mountable – 2U
Server Scalability: 2-way
Hot-Swap Bays Qty: 8
Color: Black

Processor / Chipset:
CPU: No CPU
Max CPU Qty: 2
CPU Upgradability: Upgradable
CPU Socket: Socket P
Chipset Type: Intel C621

RAM:
Installed Size: 0 GB (installed) / 2 TB (max)
Technology: DDR4 SDRAM – ECC
Form Factor: DIMM 288-pin
Slots: 16 (total) / 16 (empty)
Features: Registered, 3DS Load-Reduced DIMM (LRDIMM)
RAM Supported: 2 TB 3DS Load-Reduced – ECC ¦ 512 GB registered – ECC

Hard Drive:
Type: No HDD

Storage Controller:
Type: 1 x SATA
Controller Interface Type: SATA 6Gb/s
Channel Qty: 8
RAID Level: RAID 0, RAID 1, RAID 5, RAID 10

Optical Storage:
Type: No optical drive

Monitor:
Monitor Type: None.

Graphics Controller:
Graphics Processor: ASPEED AST2500
Video Interfaces: VGA

Networking:
Ethernet Ports: 2 x 10 Gigabit Ethernet
Ethernet Controller: Intel X722
Data Link Protocol: Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet
Remote Management Protocol: IPMI 2.0
Features: ACPI support, KVM over IP support

Expansion / Connectivity:
Bays: 8 (total) / 8 (free) x hot-swap 3.5″
Slots: 2 (total) / 2 (free) x CPU ¦ 16 (total) / 16 (free) x DIMM 288-pin ¦ 4 (total) / 4 (free) x PCIe 3.0 x16 – low-profile ¦ 2 (total) / 2 (free) x PCIe 3.0 x8 – low-profile
Interfaces: 2 x LAN (10Gigabit Ethernet) ¦ 1 x management – RJ-45 ¦ 3 x USB 3.0 (2 rear, 1 internal) ¦ 1 x VGA ¦ 4 x USB 2.0 (2 front, 2 rear) ¦ 1 x serial

Miscellaneous:
Included Accessories: 2 x CPU Heatsink
Cables Included: Serial ATA / SAS cable (2 pcs.)
Compliant Standards: RoHS

Power:
Device Type: Power supply
Power Redundancy: Yes
Power Redundancy Scheme: 1+1
Installed Qty: 2
Max Supported Qty: 2
Voltage Required: AC 120/230 V (50 – 60 Hz)
Power Provided: 1000 Watt
80 PLUS Certification: 80 PLUS Titanium
Efficiency: 96%

Manufacturer Warranty:
Service & Support: Limited warranty – parts – 1 year ¦ Limited warranty – labor – 3 years

Dimensions & Weight:
Width: 17.2 in
Depth: 25.5 in
Height: 3.5 in
Weight: 35.49 lbs

Environmental Parameters:
Min Operating Temperature: 50 °F
Max Operating Temperature: 95 °F
Humidity Range Operating: 8 – 90% (non-condensing)
