• Motherboard Supported
  • EATX
  • ATX
  • Micro ATX
  • Mini ITX
• Number of Fans Supported5
• Fan Size Supported
  • 4.72″
  • 5.51″
• Features
  • Reset Button
  • Dust Filter
  • Dual Chamber
  • Cable Management
  • Flexible Cable Clip
• Number of Internal 3.5″ Bays2
• Number of Internal 2.5″ Bays3
• Total Number of Expansion Slots7
• Total Number of USB Ports3
• USB Port Details
  • 2 x USB 3.0
  • 1 x USB Type C
• Front USBYes
• Total Number of Audio In Ports1
• Front Audio InYes
• Total Number of Audio Out Ports1
• Front Audio OutYes
• Number of Power Supplies Supported1
• Color FamilyBlack
• Product ColorBlack
• Product Material
  • Steel
  • Tempered Glass
  • Aluminium
  • Brushed Aluminum
  • Mesh
• Cooler TypeFan Cooler
• Form FactorTower
• Maximum CPU Cooler Height6.85″
• Maximum PSU Length9.13″
• Maximum GPU Length16.93″
• Height18.3″
• Width12″
• Depth18.9″
• Limited Warranty1 Year

General Information
Manufacturer: Lian Li Industrial Co., Ltd
Manufacturer Part Number: O11VX.US
Manufacturer Website Address: http://www.lian-li.com
Brand Name: Lian Li
Product Line: O11 VISION
Product Model: O11VX Black
Product Name: O11 Vision O11VX Black Computer Case
Marketing Information:

IN COLLABORATION WITH PCMR

LIAN LI joins forces with PC Master Race (PCMR) to present the O11 Vision. By combining LIAN LI’s expertise in crafting high-quality, feature-rich cases with PCMR’s community of PC enthusiasts, we created a product that builders truly desire. The result is a dual-chamber case with three sides of borderless tempered glass panels that give the clearest view of the system. The O11 Vision embodies the spirit of LIAN LI and PCMR, providing PC enthusiasts the opportunity to create their finest masterpiece.

UNOBSTRUCTED HARDWARE SHOWCASE

Display your style and showcase the power of your PC with the O11 Vision, a chassis that features three sides of tempered glass panels without any columns or pillars for the ultimate unobstructed view of the system.

BEAUTY IN EVERY ANGLE

Just like the classic O11 series, O11 Vision is available in black and white, crafted from the finest materials, and looks stunning from every angle.

• Brushed Aluminum
• 3mm Tinted Top Tempered Glass
• Inner Corner Silkscreen
• 4mm Tinted Side and Front Tempered Glass
• Black Coated Mesh Panel
• Aluminum with White Powder Coating
• 3mm Clear Top Tempered Glass
• Outer Corner White Silkscreen
• 4mm Clear Side and Front Tempered Glass
• White Coated Mesh Panel
• Brushed Aluminum
• 3mm Mirror Finish Top Tempered Glass
• 4mm Mirror Finish Side and Front Tempered Glass
• Black Coated Mesh Panel

BALANCE BETWEEN COOL AND CLEAR

The O11 Vision not only boasts a striking appearance but also doesn’t compromise on cooling capabilities thanks to its 27mm tall feet and hollowed out bottom fan bracket with 13mm elevation, ensuring ample airflow intake within the chassis.Offers support for a maximum of 2 × 360 + 1 × 240 radiators, ensuring efficient thermal control.

SEAMLESS BUILD PROCESS

Every bracket and panels are designed for modular and toolless removal, simplifying the build process and allowing for customizable configuration.

SOLID STRUCTURE

Strong structural support is designed with robust keys rated for 35kg of force, ensuring unwavering stability for all three side glass panels

TWO-WAYS REVERSIBLE SIDE FAN BRACKET

REMOVABLE BOTTOM FAN BRACKET AND DUST FILTER

Able to remove the fan bracket to install the radiator or fan with ease and clean the dust filter.

ADJUSTABLE MOTHERBOARD TRAY

Mount the motherboard, CPU pump, and graphics card outside the chassis first to make the installation process easier.

EASY TO ACCESS

The front I/O ports are strategically positioned at the bottom of the chassis, ensuring convenient access when the case is placed on a table, all while showcasing its aesthetic appeal.

THE CLEAN CABLE MANAGEMENT SOLUTION

To maintain the most aesthetic view in the main chamber, O11 Vision is designed with cable management in mind in the second chamber.

Flexible Cable Clips

Features 2 dual-layer cable clips that can be mounted anywhere along vertical grommets pass through, providing versatility for your cable routing plan.

Extended Room

The PSU mounting bracket protrudes 15mm from the rear of the case, allowing extra space for cable management. Additionally, a cable tie point along the rear of the case helps keep the rear I/O cables tidy.

MULTI-FUNCTION STORAGE BRACKET

Offering the flexibility usage of the bracket for cable routing or a drive installation.

Cable Management Bar

2.5″ SSD × 3

The removable cable managem
Product Type: Computer Case
Technical Information
Motherboard Supported:

• EATX
• ATX
• Micro ATX
• Mini ITX

Number of Fans Supported: 5
Fan Size Supported:

• 4.72″
• 5.51″

Features:

• Reset Button
• Dust Filter
• Dual Chamber
• Cable Management
• Flexible Cable Clip

Bays
Number of Internal 3.5″ Bays: 2
Number of Internal 2.5″ Bays: 3
I/O Expansions
Total Number of Expansion Slots: 7
Interfaces/Ports
Total Number of USB Ports: 3
USB Port Details:

• 2 x USB 3.0
• 1 x USB Type C

Front USB: Yes
Total Number of Audio In Ports: 1
Front Audio In: Yes
Total Number of Audio Out Ports: 1
Front Audio Out: Yes
Power Description
Number of Power Supplies Supported: 1
Physical Characteristics
Color Family: Black
Product Color: Black
Product Material:

• Steel
• Tempered Glass
• Aluminium
• Brushed Aluminum
• Mesh

Cooler Type: Fan Cooler
Form Factor: Tower
Maximum CPU Cooler Height: 6.85″
Maximum PSU Length: 9.13″
Maximum GPU Length: 16.93″
Height: 18.3″
Width: 12″
Depth: 18.9″
Warranty
Limited Warranty: 1 Year
