• Processor TypeCore i7
• Processor Generation13th Gen
• Processor Modeli7-1370P
• Processor CoreTetradeca-core (14 Core)
• Maximum Turbo Speed5.20 GHz
• 64-bit ProcessingYes
• Chipset ManufacturerIntel
• Maximum Memory Supported64 GB
• Memory TechnologyDDR4 SDRAM
• Memory StandardDDR4-3200/PC4-25600
• Intel Optane Memory ReadyNo
• Supported Storage Drive InterfacesSerial ATA
• Supported Storage Drive TypesSSD
• Controller Type
  • NVMe
  • Serial ATA
• Graphics Controller ModelIris Xe Graphics
• Graphics Memory TechnologyDDR4 SDRAM
• Graphics Memory AccessibilityShared
• Ethernet Technology2.5 Gigabit Ethernet
• Wireless LANYes
• Wireless LAN StandardIEEE 802.11ax
• BluetoothYes
• Bluetooth StandardBluetooth 5.3
• Number of M.2 Interfaces2
• HDMI (Rear)Yes
• Total Number of USB Ports7
• Number of USB 3.2 Gen 2 Type-A Ports3
• Number of Onboard USB 2.0 Ports3
• Network (RJ-45)Yes
• Number of Network (RJ-45) Ports1
• Number of Thunderbolt 4 Ports2
• Operating System Supported
  • Windows 11 Home
  • Windows 11 Pro
  • Windows 10 IoT Enterprise
  • Red Hat Linux
  • Ubuntu Linux
• Maximum Power Supply Wattage120 W
• Thermal Design Power28 W
• Height1.5″
• Width4.4″
• Depth4.6″
• Weight (Approximate)1.07 lb
• Package Contents
  • NUC 13 Pro NUC13L3Kv7 Barebone System
  • VESA Bracket
  • Power Adapter
  • VESA Mount & Screws
  • Power Cord
• Environmental ComplianceRestriction of Hazardous Substances (RoHS)

NUC 13 Pro: The Right Size for Modern Business

• Get the latest in business performance with 13th Gen Intel® Core™ processors featuring up to 14 cores (6P+8E) and up to 64GB dual-channel memory
• For professional-grade performance, the 13th Gen Intel Core™i7-1370P processor features 14 cores (6P+8E), 20 threads, 24MB Intel® Smart Cache, and 35W TDP
• Businesses get the fast memory they need with up to 64GB dual-channel DDR4-3200 SODIMMs
• Wired and wireless connections are lightning fast with up to a 2.5 Gbps Intel® Ethernet port and Intel® Wi-Fi 6E (Gig+)
• Dual HDMI 2.1 and Thunderbolt™4 ports give businesses flexibility to connect up to 4K extended displays

Business Driver. Space Saver.

NUC 13 Pro Mini PCs, Kits, and Boards offer the combination of size, performance, and reliability you need to drive modern business.

It all starts with 13th Gen Intel Core processors that deliver outsized performance in a 4×4 form factor, with up to 14 processor cores (6P+8E) and up to 64GB dual-channel DDR4 memory. Select SKUs also come with Intel vPro^® Enterprise, which provides comprehensive security, enterprise-grade stability, and hardware-based remote management.

The NUC Pro Software Suite (NPSS) helps to ensure digital signage applications keep running during any unexpected system failures. Businesses also benefit from advanced features including power control, hardware alarm clock, hardware KVM, boot redirection, beyond firewall support, cloud-based manageability, remote PC remedy, and unattended system control.

To provide an eco-friendly foundation for businesses, NUC 13 Pro Mini PCs and Kits are upgradable, reparable, and reusable. Every system is qualified for 24×7 operation.

The Mini PC That Means Business | Built for Business

Drive business growth with the perfect combination of size, performance, and reliability NUC 13 Pro is ready to work.

Built for Business

Business-class features include remote power control, hardware alarm clock, hardware KVM, boot redirection, beyond firewall support, cloud-based manageability, remote PC remedy, and unattended system control.

Intel^® Stable IT Platform Program

Take advantage of hardware stability and enterprise-level validation of key hardware components. This formal process helps reduce the number of changes that an organization would see over the life of a device. Intel SIPP program aims for no hardware driver or firmware changes for at least 15 months, or until the next generation product is released.

Comprehensive, Multilayer Security

Evolving threats require all-inclusive security features, designed to the most stringent standards. Intel^® Hardware Shield delivers integrated hardware-based PC protection, which includes below-the-OS security, application and data protection, and advanced threat detection.

Complete, Remote Management

In today’s work-at-home world, the office is everywhere. With PCs running on Intel vPro^®, IT can be everywhere too.

Sustainability

To provide an eco-friendly foundation for businesses, NUC 13 Pro Mini PCs and Kits are upgradable, repairable, and reusable.

Every system is qualified for 24×7 operation.

More from the Manufacturer

Product Type: Barebone System
Processor
Processor Type: Core i7
Processor Generation: 13th Gen
Processor Model: i7-1370P
Processor Core: Tetradeca-core (14 Core)
Maximum Turbo Speed: 5.20 GHz
64-bit Processing: Yes
Chipset
Chipset Manufacturer: Intel
Memory
Maximum Memory Supported: 64 GB
Memory Technology: DDR4 SDRAM
Memory Standard: DDR4-3200/PC4-25600
Intel Optane Memory Ready: No
Storage
Supported Storage Drive Interfaces: Serial ATA
Supported Storage Drive Types: SSD
Controllers
Controller Type:

• NVMe
• Serial ATA

Display & Graphics
Graphics Controller Model: Iris Xe Graphics
Graphics Memory Technology: DDR4 SDRAM
Graphics Memory Accessibility: Shared
Network & Communication
Ethernet Technology: 2.5 Gigabit Ethernet
Wireless LAN: Yes
Wireless LAN Standard: IEEE 802.11ax
Bluetooth: Yes
Bluetooth Standard: Bluetooth 5.3
I/O Expansions
Number of M.2 Interfaces: 2
Interfaces/Ports
HDMI (Rear): Yes
Total Number of USB Ports: 7
Number of USB 3.2 Gen 2 Type-A Ports: 3
Number of Onboard USB 2.0 Ports: 3
Network (RJ-45): Yes
Number of Network (RJ-45) Ports: 1
Number of Thunderbolt 4 Ports: 2
Operating System
Operating System Supported:

• Windows 11 Home
• Windows 11 Pro
• Windows 10 IoT Enterprise
• Red Hat Linux
• Ubuntu Linux

Power Description
Maximum Power Supply Wattage: 120 W
Thermal Design Power: 28 W
Physical Characteristics
Height: 1.5″
Width: 4.4″
Depth: 4.6″
Weight (Approximate): 1.07 lb
Miscellaneous
Package Contents:

• NUC 13 Pro NUC13L3Kv7 Barebone System
• VESA Bracket
• Power Adapter
• VESA Mount & Screws
• Power Cord

Environmental Compliance: Restriction of Hazardous Substances (RoHS)
