KIOXIA CD8-R Series KCD8DPUG15T3 15,360 GB 2.5-inch, 15mm thickness PCIe 5.0, NVMe 2.0 BiCS FLASH TLC SED SSD

Descripci車n Corta IDC-MAYORISTA:

• Capacity: 15,360 GB
• Form Factor: 2.5-inch, 15mm thickness
• lnterface: PCIe 5.0, NVMe 2.0
• Maximum Interface Speed: 128 GT/s (PCIe Gen5 x4)
• Flash Memory Type: BiCS FLASH TLC
• Performance (Up to)

  • Sustained 128 KiB Sequential Read: 12,000 MB/s
  • Sustained 128 KiB Sequential Write: 5,500 MB/s
  • Sustained 4 KiB Random Read: 2,000K IOPS
  • Sustained 4 KiB Random Write: 200K IOPS

• Power Requirements

  • Supply Voltage 12 V +/- 10 %, 3.3 V +/- 15 %
  • Power Consumption (Active): 23 W typ.
  • Power Consumption (Ready): 5 W typ.

• Reliability

  • MTTF: 2,500,000 hours
  • DWPD: 1

• Dimensions

  • Thickness: 15 mm +0 / -0.5 mm
  • Width: 69.85 mm +/- 0.25 mm
  • Length: 100.45 mm Max
  • Weight: 130 g Max

• Environmental

  • Temperature (Operating): 0 °C to 73 °C
  • Temperature (Non-operating): -40 °C to 85 °C
  • Humidity (Operating): 5 % to 95 % R.H.
  • Vibration (Operating): 21.27 m/s^2 {2.17 Grms} (5 to 800 Hz)
  • Shock (Operating): 9.8 km/s^2 {1,000 G} (0.5 ms)
