• Number of Hard Drives Supported5
• Number of Hard Drives Installed0
• Number of Solid State Drive Supported9
• Number of Solid State Drive Installed0
• Flash Memory Capacity512 MB
• Processor ManufacturerAnnapurna Labs
• Processor TypeAlpine
• Processor ModelAL-324
• Processor CoreQuad-core (4 Core)
• Processor Speed1.70 GHz
• Standard Memory4 GB
• Memory TechnologyDDR4 SDRAM
• Ethernet Technology
  • 2.5 Gigabit Ethernet
  • 10 Gigabit Ethernet
• Number of Total Expansion Bays9
• Number of 2.5″ Bays4
• Number of 2.5″/3.5″ Bays5
• Total Number of Expansion Slots2
• Expansion Slot TypeSFP+
• Controller TypeSerial ATA/600
• RAID SupportedYes
• Total Number of USB Ports3
• Number of USB 3.2 Gen 1 Ports3
• Network (RJ-45)Yes
• Number of Network (RJ-45) Ports2
• Operating SystemQTS 4.4.2
• Protocols
  • TCP/IP
  • HTTPS
  • LDAP
  • SMTP
  • L2TP
  • SFTP
  • DHCP
  • SSH
  • SMSC
  • IPSec
  • FTPS
  • AFP
  • BitTorrent
  • DNS
  • RTSP
  • FTP
  • CIFS/SMB
  • IPv4
  • WEBDAV
  • Telnet
  • SSL
  • iSCSI
  • IPMI
  • SNMP
  • TLS
  • HTTP
  • TFTP
  • NFS
  • FXP
  • UPnP
  • RSync
  • DDNS
  • IPv6
  • PPTP
• Maximum Power Supply Wattage120 W
• Height7.2″
• Width8.8″
• Depth8.8″
• Form FactorTower
• Weight (Approximate)7.47 lb
• Package Contents
  • Compact 9-bay NAS with 10GbE SFP+ and 2.5GbE for Smoother File Applications
  • 1 x Ethernet Cable
  • AC Adapter
  • 1 x Power Cord
  • 32 x Flat Head Screws (for 3.5″ HDD)
  • 24 x Flat Head Screws (for 2.5″ HDD)
  • Quick Installation Guide (QIG)
  • 2 x Drive Tray Keys
• Country of OriginTaiwan
• Limited Warranty2 Year

General Information
Manufacturer: QNAP Systems
Manufacturer Part Number: TS-932PX-4G-US
Manufacturer Website Address: http://www.qnap.com
Brand Name: QNAP
Product Model: TS-932PX-4G
Product Name: Compact 9-bay NAS with 10GbE SFP+ and 2.5GbE for Smoother File Applications
Marketing Information:

The quad-core 1.7GHz TS-932PX fits nine drive bays into the size of a 5-bay NAS. With five 3.5-inch SATA 6Gb/s drive bays and four 2.5-inch SATA 6Gb/s bays, the TS-932PX provides the ability to create an HDD/SSD hybrid infrastructure to boost application performance. With two 10GbE SFP+ and two 2.5GbE LAN ports, the TS-932PX supports next-generation networks for empowering bandwidth-demanding applications and providing smoother file access and sharing.

• Two 10GbE SFP+ and two 2.5GbE RJ45 network ports empower bandwidth-demanding tasks and accelerate file sharing.

• HBS provides comprehensive backup and data recovery; QuDedup deduplicates the data at the source to optimize storage and bandwidth usage, while reducing backup times.

• Snapshots record your system status, allowing you to protect files and data from accidental deletion and malware attacks.

• Cloud storage gateways realize hybrid cloud applications by working with the cache space reserved on NAS to ensure low-latency data access to the cloud.

• Qtier™ auto-tiering technology and SSD caching enable constant storage optimization.

• Increase the storage capacity of the TS-932PX with QNAP TR RAID expansion enclosures or TL JBOD.

Energy-efficient Quad-core Processor

Powered by 64-bit quad-core 1.7GHz ARM Cortex-A57 processor and 4 GB DDR4 RAM (expandable to 16 GB), the TS-932PX features is highly energy efficient without impacting system or application performance.

High-speed 10GbE and 2.5GbE connectivity

The TS-932PX includes two 10GbE SFP+ and two 2.5GbE LAN RJ45 ports, providing out-of-the-box support for high-speed networking and supporting Port Trunking and Failover to reinforce your network infrastructure. QNAP also provide many other high-speed networking solutions, including 10GbE/2.5GbE managed/unmanaged switches and network adapters, allowing you to build a budget-friendly high-speed network environment.

Boost NAS performance with 2.5-inch SATA SSDs

SSDs can greatly improve NAS performance without requiring a heavy investment. The TS-932PX supports SSD cache technology, Qtier™ auto-tiering, and SSD over-provisioning, helping you to balance storage performance, storage allocation, and IT expenses.

Protect Important Data with Snapshots

Snapshots fully record the NAS system state and metadata and can be used to quickly restore files to previously-recorded states if they are accidentally deleted/modified or if the system is compromised by ransomware. QNAP snapshots are block-based and only record modified data. Not only does this save storage space, but also reduces the time required to back up and restore data. The TS-932PX supports up to 256 snapshots per NAS and up to 64 snapshots per volume or LUN.

Multi-Point File Backup, Access, and Sync

The TS-932PX supports common file sharing protocols (including SMB/CIFS, AFP and NFS) for Windows®, Mac®, and Linux®/UNIX® devices. Coupled with Qsync (a utility that transforms a QNAP NAS into a secure, high-capacity data center for file synchronization) any file uploaded to the TS-932PX becomes available for all linked devices (such as computers, laptops, and mobile devices). Hybrid Backup Sync helps you easily backup or synchronize data on the TS-932PX to another QNAP NAS, remote server, or cloud storage (including Microsoft One Drive®, Google Drive™, and Dropbox®) for disaster recovery.

Product Type: SAN/NAS Storage System
Storage
Number of Hard Drives Supported: 5
Number of Hard Drives Installed: 0
Number of Solid State Drive Supported: 9
Number of Solid State Drive Installed: 0
Flash Memory Capacity: 512 MB
Processor & Chipset
Processor Manufacturer: Annapurna Labs
Processor Type: Alpine
Processor Model: AL-324
Processor Core: Quad-core (4 Core)
Processor Speed: 1.70 GHz
Memory
Standard Memory: 4 GB
Memory Technology: DDR4 SDRAM
Network & Communication
Ethernet Technology:

• 2.5 Gigabit Ethernet
• 10 Gigabit Ethernet

I/O Expansions
Number of Total Expansion Bays: 9
Number of 2.5″ Bays: 4
Number of 2.5″/3.5″ Bays: 5
Total Number of Expansion Slots: 2
Expansion Slot Type: SFP+
Controllers
Controller Type: Serial ATA/600
RAID Supported: Yes
Interfaces/Ports
Total Number of USB Ports: 3
Number of USB 3.2 Gen 1 Ports: 3
Network (RJ-45): Yes
Number of Network (RJ-45) Ports: 2
Software
Operating System: QTS 4.4.2
Management & Protocols
Protocols:

• TCP/IP
• HTTPS
• LDAP
• SMTP
• L2TP
• SFTP
• DHCP
• SSH
• SMSC
• IPSec
• FTPS
• AFP
• BitTorrent
• DNS
• RTSP
• FTP
• CIFS/SMB
• IPv4
• WEBDAV
• Telnet
• SSL
• iSCSI
• IPMI
• SNMP
• TLS
• HTTP
• TFTP
• NFS
• FXP
• UPnP
• RSync
• DDNS
• IPv6
• PPTP

Power Description
Maximum Power Supply Wattage: 120 W
Physical Characteristics
Height: 7.2″
Width: 8.8″
Depth: 8.8″
Form Factor: Tower
Weight (Approximate): 7.47 lb
Miscellaneous
Package Contents:

• Compact 9-bay NAS with 10GbE SFP+ and 2.5GbE for Smoother File Applications
• 1 x Ethernet Cable
• AC Adapter
• 1 x Power Cord
• 32 x Flat Head Screws (for 3.5″ HDD)
• 24 x Flat Head Screws (for 2.5″ HDD)
• Quick Installation Guide (QIG)
• 2 x Drive Tray Keys

Country of Origin: Taiwan
Warranty
Limited Warranty: 2 Year
