• Chipset ManufacturerIntel
• Chipset ModelC602-J
• Total Processor Supported2
• Processor SocketSocket R LGA-2011
• Processor SupportedXeon
• QuickPath Interconnect8 GT/s
• 64-bit ProcessingYes
• Number of Memory Slots16
• Memory Form Factor
  • DIMM
  • RDIMM
  • UDIMM
  • LRDIMM
• Maximum Memory Supported512 GB
• Memory Standard
  • DDR3-1600/PC3-12800
  • DDR3-1333/PC3-10600
  • DDR3-1066/PC3-8500
  • DDR3-800/PC3-6400
• Memory TechnologyDDR3 SDRAM
• Memory Speed Supported
  • 1600 MHz
  • 1333 MHz
  • 1066 MHz
  • 800 MHz
• Controller Type
  • Serial ATA/300
  • Serial ATA/600
• RAID SupportedYes
• RAID Levels
  • 0
  • 1
  • 5
  • 1+0
• Onboard VideoOn-board Video Chipset
• Graphics Controller ModelG200eW
• Gigabit EthernetYes
• Total Number of Expansion Slots6
• PCI Express StandardPCI Express 3.0
• Total Number of PCI Express Slots6
• Number of PCI Express x8 Slots6
• Total Number of USB Ports4
• Number of USB 2.0 Ports4
• Serial PortYes
• Audio Line InNo
• Audio Line OutNo
• Microphone PortNo
• VGAYes
• Network (RJ-45)Yes
• Number of Network (RJ-45) Ports3
• Number of SATA Interfaces6
• Total Number of Onboard USB Ports5
• Number of Onboard USB 2.0 Ports5
• Onboard Serial HeaderYes
• Onboard LEDs HeaderYes
• Power Supply SupportedEPS12V
• Form FactorExtended ATX
• Height3″
• Width13″
• Depth12″
• Weight (Approximate)7 lb
• Certifications & Standards
  • FCC
  • CE
• Environmentally FriendlyYes
• Environmental ComplianceRestriction of Hazardous Substances (RoHS)
• Limited Warranty3 Year

Major Benefits from Supermicro’s in-house Design Superiority

Supermicro motherboard advantages:

• Technologically-advanced Motherboard Designs Since 1993
• Consistent highest-quality Design, Components, and Production Expertise
• Extensive Range of x86 Serverboards Available
• Competitive Price/Performance
• High Performance Boards Supporting the Latest CPU, memory, and add-on Hardware
• Standard Form Factors offer Feature – rich Support and application optimization

These competitive advantages help Supermicro maintain its design leadership in providing state-of-the-art motherboards for a wide range of applications. Always a step ahead of the competition, Supermicro is consistently first-to-market in delivering high-performance technology support. Offering the most extensive serverboard selection in the industry at competitive prices, Supermicro boards are quality-built to maximize customer satisfaction.

Package Type: Bulk
Product Type: Server Motherboard
Processor & Chipset
Chipset Manufacturer: Intel
Chipset Model: C602-J
Total Processor Supported: 2
Processor Socket: Socket R LGA-2011
Processor Supported: Xeon
QuickPath Interconnect: 8 GT/s
64-bit Processing: Yes
Memory
Number of Memory Slots: 16
Memory Form Factor:

• DIMM
• RDIMM
• UDIMM
• LRDIMM

Maximum Memory Supported: 512 GB
Memory Standard:

• DDR3-1600/PC3-12800
• DDR3-1333/PC3-10600
• DDR3-1066/PC3-8500
• DDR3-800/PC3-6400

Memory Technology: DDR3 SDRAM
Memory Speed Supported:

• 1600 MHz
• 1333 MHz
• 1066 MHz
• 800 MHz

I/O Controller
Controller Type:

• Serial ATA/300
• Serial ATA/600

RAID Supported: Yes
RAID Levels:

• 0
• 1
• 5
• 1+0

Video
Onboard Video: On-board Video Chipset
Graphics Controller Model: G200eW
Network & Communication
Gigabit Ethernet: Yes
I/O Expansions
Total Number of Expansion Slots: 6
PCI Express Standard: PCI Express 3.0
Total Number of PCI Express Slots: 6
Number of PCI Express x8 Slots: 6
Interfaces/Ports
Total Number of USB Ports: 4
Number of USB 2.0 Ports: 4
Serial Port: Yes
Audio Line In: No
Audio Line Out: No
Microphone Port: No
VGA: Yes
Network (RJ-45): Yes
Number of Network (RJ-45) Ports: 3
Onboard Interfaces
Number of SATA Interfaces: 6
Total Number of Onboard USB Ports: 5
Number of Onboard USB 2.0 Ports: 5
Onboard Serial Header: Yes
Onboard LEDs Header: Yes
Power Description
Power Supply Supported: EPS12V
Physical Characteristics
Form Factor: Extended ATX
Height: 3″
Width: 13″
Depth: 12″
Weight (Approximate): 7 lb
Miscellaneous
Certifications & Standards:

• FCC
• CE

Environmentally Friendly: Yes
Environmental Compliance: Restriction of Hazardous Substances (RoHS)
Warranty
Limited Warranty: 3 Year
