• Storage Capacity1.60 TB
• Features
  • Power Loss Protection (PLP)
  • Error Correction Code (ECC)
• Random 4KB Read660000IOPS
• Random 4KB Write120000IOPS
• Endurance (TBW)2900 TB
• Maximum Sequential Read2.93 GB/s
• Maximum Sequential Write1000 MB/s
• Mean Time Between Failures (MTBF)342.2 Year
• Drive InterfacePCI Express NVMe
• Drive Interface StandardPCI Express NVMe 3.0 x4
• Drive TypeInternal
• Form FactorM.2 2280
• Height0.1″
• Width0.9″
• Depth3.1″
• Device Supported
  • Storage System
  • Server
  • NAS

Durable SSDs Built for Demanding Caching Workloads

Synology Enterprise Series M.2 NVMe SSDs are designed to handle demanding caching workloads in 24/7 high-concurrency scenarios. Their strong sustained I/O performance makes them ideal for systems used as highperformance file servers, database storage, and virtualization environments. These drives feature advanced lifetime analytics1 and are backed by Synology’s 5-year limited warranty

Caching for Enterprise Workloads

Enterprise Series M.2 NVMe drives are engineered to deliver reliable, highspeed caching in demanding 24/7 environments, enhancing I/O performance and minimizing latency. With up to 660,000/120,000 4K random read/write IOPS3 and up to a 2,900 TBW endurance rating,4 these drives offer a robust caching solution ideal for multi-user environments, all without occupying 3.5″ drive bays.

Data Integrity Safeguards

SSD caching boosts system read/write performance by storing transient data in solid-state drives to increase retrieval efficiency and by reducing reoccurring requests to the primary storage. Data integrity is important, as cached data are continuously relocated. Synology Enterprise Series M.2 NVMe SSDs drives offer end-to-end data protection to safeguard data integrity over the entire transfer path. SNV5400 Series drives feature a power loss protection circuit design6 with dedicated capacitors. This system prevents data corruption during abnormal shutdowns by ensuring data-in-flight is safely written to NAND flash. Additionally, the firmware enables a proper restart upon the next power-up.

Real-World Workload Analytics

Full integration with Synology DiskStation Manager (DSM) operating system allows Synology systems to provide lifetime analytics1 based on actual workloads. This enables easy monitoring, allowing users to track SSD usage and make optimal use of each drive. Additionally, the system provides timely notifications of drive health and remaining life, aiding system administrators in planning ahead for replacements to ensure uninterrupted system performance.

Purpose-Built for Synology Systems

Synology M.2 NVMe SSDs are rigorously tested for compatibility with Synology systems following each engineering change, with firmware and component changes strictly managed to ensure optimal performance and reliability. Firmware updates can be easily installed through Synology DiskStation Manager (DSM) with a single click.5 All products undergo intensive I/O stress, power cycling, and temperature trials to meet Synology’s strictest standards for quality and reliability, guaranteeing consistent performance and compatibility.

Product Type: Solid State Drive
Technical Information
Storage Capacity: 1.60 TB
Features:

• Power Loss Protection (PLP)
• Error Correction Code (ECC)

Drive Performance
Random 4KB Read: 660000IOPS
Random 4KB Write: 120000IOPS
Endurance (TBW): 2900 TB
Maximum Sequential Read: 2.93 GB/s
Maximum Sequential Write: 1000 MB/s
Mean Time Between Failures (MTBF): 342.2 Year
Interfaces/Ports
Drive Interface: PCI Express NVMe
Drive Interface Standard: PCI Express NVMe 3.0 x4
Physical Characteristics
Drive Type: Internal
Form Factor: M.2 2280
Height: 0.1″
Width: 0.9″
Depth: 3.1″
Miscellaneous
Device Supported:

• Storage System
• Server
• NAS
