• Number of Hard Drives Supported24
• Number of Hard Drives Installed0
• Number of Solid State Drive Supported24
• Number of Solid State Drive Installed0
• Processor ManufacturerIntel
• Processor TypeXeon
• Processor ModelD-1567
• Processor CoreDodeca-core (12 Core)
• Processor Speed2.10 GHz
• Standard Memory16 GB
• Memory TechnologyDDR4 SDRAM
• Ethernet Technology10 Gigabit Ethernet
• Number of Total Expansion Bays24
• Number of 2.5″ Bays24
• Total Number of Expansion Slots1
• Expansion Slot TypePCI Express 3.0 x8
• Controller TypeSerial Attached SCSI (SAS)
• RAID SupportedYes
• RAID Levels0, 1, 5, 6, 10, Basic, JBOD, RAID F1
• Number of SAS Ports (External)1
• Total Number of USB Ports2
• Number of USB 3.0 Ports2
• Network (RJ-45)Yes
• Number of Network (RJ-45) Ports6
• Operating SystemDiskStation Manager
• Protocols
  • SMB
  • AFP
  • NFS
  • FTP
  • WEBDAV
  • CalDAV
  • iSCSI
  • Telnet
  • SSH
  • SNMP
  • PPTP
  • L2TP
  • LDAP
  • HTTPS
  • SSL/TLS
  • SFTP
  • TFTP
  • SMTP
  • POP3
• Number of Power Supplies Installed2
• Maximum Power Supply Wattage500 W
• Redundant Power SupplyYes
• Height3.5″
• Width19″
• Depth28.5″
• Form FactorRack-mountable
• Rack Height2U
• Weight (Approximate)32.85 lb
• Country of OriginTaiwan

• Accelerate Your Business with an Affordable All-Flash Solution

  FS3600 is a 24-bay all-flash server for enterprises to boost the performance of I/O sensitive applications such as database, virtual machines, or OLTP, with a competitive TCO. Powered by Synology’s award-winning DiskStation Manager (DSM) operating system, FS3600 makes data management tasks efficient and simple from a single pane of glass. The feature-rich, integrated data protection mechanisms can further ensure service availability.


  Fast, Scalable, and Affordable


  FS3600 is an all-flash data management solution delivering more than 193,000 iSCSI 4K random write IOPS, ideal for enterprises pursuing a high-speed infrastructure that responds fast under I/O intensive workloads, such as database, virtual machines, or OLTP applications. FS3600 is 10GbE-ready and can be easily integrated to businesses’ existing LAN environment, with a competitive cost per Gigabyte ratio at

• 0.23/GB.

  Powered by Synology DiskStation Manager (DSM), an award-winning and web-based operating system, FS3600 provides an intuitive graphical user interface for IT administrators to manage and monitor system resource easily and efficiently. FS3600 supports easy storage capacity expansion with Synology Expansion Unit RX1217sas/RX2417sas, with no need to remove existing data or install additional management software.

  Built for Your SAN Storage Needs


  Synology FS3600 provides a fully certified virtualization solution with VMware® vSphere™, Microsoft® Hyper-V®, Citrix® XenServer™, and OpenStack Cinder. It supports both iSCSI and NFS protocols and integrates with VMware VAAI and Microsoft ODX, allowing IT administrators to effectively deploy and facilitate storage operations in various virtualization environments. IT administrators can efficiently manage virtualized workloads through built-in DSM features and add-on plugins for VMware and Windows environments. Features including fast clone, NFS v4.1, and thin provisioning deliver more flexibility to accommodate to administration needs.

  With no additional license fees required, your virtualized workload can be further protected by a complete suite of data protection applications including Synology Snapshot Replication, Hyper Backup, Active Backup for Business and Synology High Availability to cover various protection scenarios.

  Virtualize Workloads Flexibly in a Protected Environment

  Synology Virtual Machine Manager (VMM) is an intuitive hypervisor software application allowing you to easily set up virtual machines and run various operating systems, including Windows, Linux and Virtual DSM. Besides, you can build up a cluster environment with multiple Synology systems while keeping the flexibility to scale out online and migrate virtual machines for load balancing and resource allocation. Each virtual machines can also be fully protected by a set of disaster recovery features including instant snapshot, replication, clone, restore and failover, safeguarding your digital assets with no additional cost.

  With VMM Pro license, you can further utilize the advanced features of remote replication, remote storage migration, high availability and live migration, minimizing the risk of service downtime and managing IT resources agilely.

Packaged Quantity: 1
Product Type: SAN/NAS Storage System
Storage
Number of Hard Drives Supported: 24
Number of Hard Drives Installed: 0
Number of Solid State Drive Supported: 24
Number of Solid State Drive Installed: 0
Processor & Chipset
Processor Manufacturer: Intel
Processor Type: Xeon
Processor Model: D-1567
Processor Core: Dodeca-core (12 Core)
Processor Speed: 2.10 GHz
Memory
Standard Memory: 16 GB
Memory Technology: DDR4 SDRAM
Network & Communication
Ethernet Technology: 10 Gigabit Ethernet
I/O Expansions
Number of Total Expansion Bays: 24
Number of 2.5″ Bays: 24
Total Number of Expansion Slots: 1
Expansion Slot Type: PCI Express 3.0 x8
Controllers
Controller Type: Serial Attached SCSI (SAS)
RAID Supported: Yes
RAID Levels: 0, 1, 5, 6, 10, Basic, JBOD, RAID F1
Interfaces/Ports
Number of SAS Ports (External): 1
Total Number of USB Ports: 2
Number of USB 3.0 Ports: 2
Network (RJ-45): Yes
Number of Network (RJ-45) Ports: 6
Software
Operating System: DiskStation Manager
Management & Protocols
Protocols:

• SMB
• AFP
• NFS
• FTP
• WEBDAV
• CalDAV
• iSCSI
• Telnet
• SSH
• SNMP
• PPTP
• L2TP
• LDAP
• HTTPS
• SSL/TLS
• SFTP
• TFTP
• SMTP
• POP3

Power Description
Number of Power Supplies Installed: 2
Maximum Power Supply Wattage: 500 W
Redundant Power Supply: Yes
Physical Characteristics
Height: 3.5″
Width: 19″
Depth: 28.5″
Form Factor: Rack-mountable
Rack Height: 2U
Weight (Approximate): 32.85 lb
Miscellaneous
Country of Origin: Taiwan
