• AI-poweredYes
• Chipset ManufacturerAMD
• Chipset ModelB850
• Total Processor Supported1
• Processor SocketSocket AM5
• Processor Supported
  • Ryzen 7
  • Ryzen 8
  • Ryzen 9
• Number of Memory Slots4
• Memory Form Factor
  • DIMM
  • UDIMM
• Maximum Memory Supported256 GB
• Memory TechnologyDDR5 SDRAM
• Memory Speed Supported8000 MHz
• Error CheckingECC
• Controller TypeSerial ATA/600
• RAID SupportedYes
• RAID Levels
  • 0
  • 1
  • 5
  • 10
• Onboard VideoCPU Dependent Video
• Audio Channels7.1
• BluetoothYes
• Bluetooth StandardBluetooth 5.3
• Gigabit EthernetYes
• 2.5Gigabit EthernetYes
• Wireless LANYes
• Wireless LAN StandardIEEE 802.11ax
• Total Number of Expansion Slots4
• PCI Express Standard
  • PCI Express 4.0
  • PCI Express 5.0
• Total Number of PCI Express Slots4
• Number of PCI Express x1 Slots1
• Number of PCI Express x16 Slots3
• Total Number of USB Ports8
• HDMIYes
• HDMI Version2.1
• DisplayPortYes
• Number of Network (RJ-45) Ports1
• Number of SATA Interfaces4
• Number of M.2 Interfaces3
• Total Number of Onboard USB Ports7
• Number of Onboard USB 2.0 Ports4
• Form FactorATX
• Width12″
• Depth9.6″
• Package Contents
  • GAMING B850-E WIFI Gaming Desktop Motherboard
  • 2 x SATA 6Gb/s cables
  • 1 x ASUS WiFi Q-Antenna
  • 1 x TUF GAMING sticker
  • ‘ x M.2 rubber packages
  • 1 x Screw package for M.2 SSD
  • 1 x Quick start guide
• Brand CompatibilityAMD
• Environmental ComplianceRestriction of Hazardous Substances (RoHS)

General Information
Manufacturer: ASUS Computer International
Manufacturer Part Number: TUF GAMING B850-E WIFI
Manufacturer Website Address: http://usa.asus.com
Brand Name: TUF
Product Model: GAMING B850-E WIFI
Product Name: GAMING B850-E WIFI Gaming Desktop Motherboard
Marketing Information:

ASUS TUF GAMING B850-E WIFI takes all the essential elements of the latest AMD Ryzen™ processors and combines them with game-ready features and proven durability. Engineered with military-grade components, an upgraded power solution and a comprehensive cooling system, this motherboard goes beyond expectations with rock-solid and stable performance for marathon gaming. TUF GAMING motherboards also undergo rigorous endurance testing to ensure that they can handle conditions where others may fail. This platform delivers the power and connectivity that advanced AI PC applications demand.

AI Advisor

ASUS AI Advisor is an ASUS technical expert that’s always available to answer your questions. Owners of compatible ASUS motherboards can interact with this AI-powered technology using natural language to learn more about their hardware. For DIY beginners, it can provide easy-to-understand explanations of one-click optimization features like AI Overclocking and fan speed tuning, and for seasoned PC-building veterans, it can offer guidance and instructions on the latest features offered by ASUS.

UEFI BIOS

The UEFI interface delivers easy-to-use configuration options for PC beginners, and advanced features for veterans.

ASUS DriverHub

Simplify driver management with automatic detection, one-click installation and update for smooth, efficient system performance.

ASUS GlideX

Enable seamless screen sharing and control across PCs, tablets, and smartphones via USB or WiFi, supporting multiple platforms.

Power Saving

Leverage all-around energy efficiency settings to optimize power consumption

Armoury Crate

Customize Aura Sync RGB and control ASUS devices. Includes product registration and updates.

Premium Power Design

Stable power is crucial for maximizing the performance of AMD processors. The motherboard is designed to meet the needs of high-core-count CPUs. It features 8(80A) + 2(80A) + 1(80A) power stages that integrate high-side and low-side MOSFETs and drivers into packages rated for up to 80A each. This configuration ensures optimal power delivery, efficiency, stability and performance for both current and future AMD processors.

DRAM Overclocking Performance

Comprehensive memory tuning options are the cornerstone of TUF GAMING motherboards. With the motherboard, you can extract all the potential out of your DDR5 modules*, whether they’re from an extreme-speed kit or an entry-level set that would otherwise be locked.

DDR5 DOMINANCE

For those who want to fly past stock DDR5 speeds, this motherboard is primed and ready for enthusiast-grade kits, courtesy of vast AMD Extended Profiles for Overclocking (EXPO™) support. Seasoned veterans can further tweak performance via an extensive array of settings in the UEFI.

Product Type: Gaming Desktop Motherboard
Technical Information
AI-powered: Yes
Processor & Chipset
Chipset Manufacturer: AMD
Chipset Model: B850
Total Processor Supported: 1
Processor Socket: Socket AM5
Processor Supported:

• Ryzen 7
• Ryzen 8
• Ryzen 9

Memory
Number of Memory Slots: 4
Memory Form Factor:

• DIMM
• UDIMM

Maximum Memory Supported: 256 GB
Memory Technology: DDR5 SDRAM
Memory Speed Supported: 8000 MHz
Error Checking: ECC
I/O Controller
Controller Type: Serial ATA/600
RAID Supported: Yes
RAID Levels:

• 0
• 1
• 5
• 10

Video
Onboard Video: CPU Dependent Video
Audio
Audio Channels: 7.1
Network & Communication
Bluetooth: Yes
Bluetooth Standard: Bluetooth 5.3
Gigabit Ethernet: Yes
2.5Gigabit Ethernet: Yes
Wireless LAN: Yes
Wireless LAN Standard: IEEE 802.11ax
I/O Expansions
Total Number of Expansion Slots: 4
PCI Express Standard:

• PCI Express 4.0
• PCI Express 5.0

Total Number of PCI Express Slots: 4
Number of PCI Express x1 Slots: 1
Number of PCI Express x16 Slots: 3
Interfaces/Ports
Total Number of USB Ports: 8
HDMI: Yes
HDMI Version: 2.1
DisplayPort: Yes
Number of Network (RJ-45) Ports: 1
Onboard Interfaces
Number of SATA Interfaces: 4
Number of M.2 Interfaces: 3
Total Number of Onboard USB Ports: 7
Number of Onboard USB 2.0 Ports: 4
Physical Characteristics
Form Factor: ATX
Width: 12″
Depth: 9.6″
Miscellaneous
Package Contents:

• GAMING B850-E WIFI Gaming Desktop Motherboard
• 2 x SATA 6Gb/s cables
• 1 x ASUS WiFi Q-Antenna
• 1 x TUF GAMING sticker
• ‘ x M.2 rubber packages
• 1 x Screw package for M.2 SSD
• 1 x Quick start guide

Brand Compatibility: AMD
Environmental Compliance: Restriction of Hazardous Substances (RoHS)
