• Storage Capacity6.25 TB
• Maximum Read Transfer Rate7100 MB/s
• Maximum Write Transfer Rate6000 MB/s
• Random 4KB Read1150000IOPS
• Random 4KB Write380000IOPS
• Endurance (DWPD)3
• Endurance TypeMixed Use
• Drive InterfacePCI Express NVMe
• Drive Interface StandardPCI Express NVMe 4.0 x4
• Drive TypeInternal
• Form Factor2.5″
• Height0.6″
• Width2.8″
• Length4″
• Weight (Approximate)4.59 oz
• Device Supported
  • Storage System
  • Server

KIOXIA CD8-V Series is a mixed use data center NVMe™ SSD that is optimized to support a broad range of scale-out and cloud applications, including big data/IoT, online transaction pro-cessing and virtualization. Built with a PCIe® 4.0 (16 GT/s x4) interface, the CD8-V Series SSDs deliver consistent performance up to 1,250K IOPS (random read) and 380K IOPS (random write).

Featuring KIOXIA 112-layer BiCS FLASH™ 3D TLC flash memory, the CD8-V 2.5-inch form factor SSDs deliver 3 DWPD (Drive Writes Per Day) of endurance and storage capacities up to 12.8 TB in a 2.5-inch form factor, making them well-suited for hyperscale data center applications.

Key Features

• PCIe® 4.0, NVMe™ 1.4 specification compliant
• Open Compute Project Datacenter NVMe™ SSD specification v2.0 support (not all requirements)
• Form factor: 2.5-inch, 15mm thickness
• Proprietary KIOXIA architecture: controller, firmware and 112-layer BiCS FLASH™ 3D TLC
• Single-port design, optimized for data center class workloads
• Consistent performance and reliability for demanding 24×7 environments
• Designed for high-density storage deployments
• Power loss protection (PLP) and end-to-end data correction
• Security options: SIE, SED

Key Applications

• Hyperscale
• IoT and big data analytics
• Online transaction processing (OLTP) (transactional and relational databases)
• Virtualized environments
• Streaming media and content delivery network

Product Type: Solid State Drive
Technical Information
Storage Capacity: 6.25 TB
Drive Performance
Maximum Read Transfer Rate: 7100 MB/s
Maximum Write Transfer Rate: 6000 MB/s
Random 4KB Read: 1150000IOPS
Random 4KB Write: 380000IOPS
Endurance (DWPD): 3
Endurance Type: Mixed Use
Interfaces/Ports
Drive Interface: PCI Express NVMe
Drive Interface Standard: PCI Express NVMe 4.0 x4
Physical Characteristics
Drive Type: Internal
Form Factor: 2.5″
Height: 0.6″
Width: 2.8″
Length: 4″
Weight (Approximate): 4.59 oz
Miscellaneous
Device Supported:

• Storage System
• Server
