• Number of Processors Supported2
• Processor SocketSocket LGA-4677
• Processor Supported
  • Xeon Platinum
  • Xeon Gold
  • Xeon Silver
  • Xeon Bronze
• 64-bit ProcessingYes
• Chipset ManufacturerIntel
• Chipset ModelC741
• Maximum Memory Supported4 TB
• Memory TechnologyDDR5 SDRAM
• Memory StandardDDR5-4800/PC5-38400
• Total Number of Memory Slots16
• Supported Storage Drive Interfaces
  • SAS
  • Serial ATA
  • PCI Express
• Controller TypeSerial ATA/600
• RAID SupportedYes
• RAID Levels0, 1, 5, 10
• Ethernet Technology10 Gigabit Ethernet
• Number of Total Expansion Bays8
• Number of 3.5″ Bays8
• Total Number of Expansion Slots7
• Number of PCI Express x16 Slots7
• Number of M.2 Interfaces2
• Network (RJ-45)Yes
• Number of Network (RJ-45) Ports2
• Number of VGA Ports1
• Input Voltage
  • 120 V AC
  • 230 V AC
• Number of Power Supplies Installed2
• Maximum Power Supply Wattage2000 W
• Frequency
  • 50 Hz
  • 60 Hz
• Color FamilyDual Color
• Product Color
  • Black
  • Silver
• Form FactorTower
• Height7″
• Width17.2″
• Depth29″
• Weight (Approximate)46.08 lb
• Package Contents
• SuperServer SYS-741GE-TNRT (Black Front & Silver Body)
• 1 x Super X13DEG-QT Motherboard
• 1 x Tower Chassis
• 1 x 8-port 3.5″ LFF direct-attached HDD SAS4/NVMe Gen5 backplane for 4U SC749 Tower, all ports support 32GT/s NVMe Gen5 and/or 24Gb/s SAS4.,RoHS
• 4 x MCIOx8 (STR_pTab to LE), 40cm,30AWG,RoHS
• 1 x MicroHi(2×4 to 2×4), PH3.0, 40cm, 8.5A/p, 18AWG, RoHS
• 2 x Slimline x4 (LE) to Slimline x4 (STR),INT,30CM,100 OHM,
• 1 x ROUND 16 TO 16 PIN RIBBON FP CABLE 30″L, LF US POWER CORD 16AWG, PB FREE PWEX,FAN,1X4/P2.5 TO 1X4/P2.54,20CM,22AWG,5A/PIN,RoHS
• 1 x STD I/O Shield for X13DEG-QT with EMI Gasket & Black Mylar
• 1 x Black plastic top cover for SC747
• 1 x fixed 3.5″ dummy cover for SC747
• 1 x Plastic feet (2 pcs/set) for 4U tower chassis, black color
• 1 x License key for enabling OOB BIOS management
• 2 x 4U Active CPU HS for X13 Gen. Intel Eagle Stream Platform
• 2 x 1U 2000W Redundant Titanium Power Supply W/PMbus 73.5x40x265mm,RoHS/REACH
• 1 x 4U 4GPU support redundancy 2PWS up to 3KW output pass thr
• 1 x 92x92x38 mm, 11.5K RPM Cooling fan w/ 5A Fan Connector,RoHS
• 4 x 92x92x38 mm, 11.5K RPM Cooling fan w/ 5A Fan Connector,RoHS
• 1 x SC747 plastic front bezel
• 3 x Black 5.25 drive tray w/o rail (SC747)
• 8 x NVMe Panetone 159C on Latch
• 1 x SC747BTQ-R2K04B Front Control Panel PCB (2x USB3.0, Audio)
• Limited Warranty1 Year
• Additional Warranty InformationSupermicro provides a three-year warranty for labor and one-year warranty for parts.

General Information
Manufacturer: Supermicro Computer, Inc
Manufacturer Part Number: SYS741GETNRT
Manufacturer Website Address: http://www.supermicro.com
Brand Name: Supermicro
Product Line: SuperServer
Product Model: 741GE-TNRT
Product Name: SuperServer SYS-741GE-TNRT (Black Front & Silver Body)
Product Type: Server Barebone System
Processor
Number of Processors Supported: 2
Processor Socket: Socket LGA-4677
Processor Supported:

• Xeon Platinum
• Xeon Gold
• Xeon Silver
• Xeon Bronze

64-bit Processing: Yes
Chipset
Chipset Manufacturer: Intel
Chipset Model: C741
Memory
Maximum Memory Supported: 4 TB
Memory Technology: DDR5 SDRAM
Memory Standard: DDR5-4800/PC5-38400
Total Number of Memory Slots: 16
Storage
Supported Storage Drive Interfaces:

• SAS
• Serial ATA
• PCI Express

Controllers
Controller Type: Serial ATA/600
RAID Supported: Yes
RAID Levels: 0, 1, 5, 10
Network & Communication
Ethernet Technology: 10 Gigabit Ethernet
I/O Expansions
Number of Total Expansion Bays: 8
Number of 3.5″ Bays: 8
Total Number of Expansion Slots: 7
Number of PCI Express x16 Slots: 7
Number of M.2 Interfaces: 2
Interfaces/Ports
Network (RJ-45): Yes
Number of Network (RJ-45) Ports: 2
Number of VGA Ports: 1
Power Description
Input Voltage:

• 120 V AC
• 230 V AC

Number of Power Supplies Installed: 2
Maximum Power Supply Wattage: 2000 W
Frequency:

• 50 Hz
• 60 Hz

Physical Characteristics
Color Family: Dual Color
Product Color:

• Black
• Silver

Form Factor: Tower
Height: 7″
Width: 17.2″
Depth: 29″
Weight (Approximate): 46.08 lb
Miscellaneous
Package Contents:

• SuperServer SYS-741GE-TNRT (Black Front & Silver Body)
• 1 x Super X13DEG-QT Motherboard
• 1 x Tower Chassis
• 1 x 8-port 3.5″ LFF direct-attached HDD SAS4/NVMe Gen5 backplane for 4U SC749 Tower, all ports support 32GT/s NVMe Gen5 and/or 24Gb/s SAS4.,RoHS
• 4 x MCIOx8 (STR_pTab to LE), 40cm,30AWG,RoHS
• 1 x MicroHi(2×4 to 2×4), PH3.0, 40cm, 8.5A/p, 18AWG, RoHS
• 2 x Slimline x4 (LE) to Slimline x4 (STR),INT,30CM,100 OHM,
• 1 x ROUND 16 TO 16 PIN RIBBON FP CABLE 30″L, LF US POWER CORD 16AWG, PB FREE PWEX,FAN,1X4/P2.5 TO 1X4/P2.54,20CM,22AWG,5A/PIN,RoHS
• 1 x STD I/O Shield for X13DEG-QT with EMI Gasket & Black Mylar
• 1 x Black plastic top cover for SC747
• 1 x fixed 3.5″ dummy cover for SC747
• 1 x Plastic feet (2 pcs/set) for 4U tower chassis, black color
• 1 x License key for enabling OOB BIOS management
• 2 x 4U Active CPU HS for X13 Gen. Intel Eagle Stream Platform
• 2 x 1U 2000W Redundant Titanium Power Supply W/PMbus 73.5x40x265mm,RoHS/REACH
• 1 x 4U 4GPU support redundancy 2PWS up to 3KW output pass thr
• 1 x 92x92x38 mm, 11.5K RPM Cooling fan w/ 5A Fan Connector,RoHS
• 4 x 92x92x38 mm, 11.5K RPM Cooling fan w/ 5A Fan Connector,RoHS
• 1 x SC747 plastic front bezel
• 3 x Black 5.25 drive tray w/o rail (SC747)
• 8 x NVMe Panetone 159C on Latch
• 1 x SC747BTQ-R2K04B Front Control Panel PCB (2x USB3.0, Audio)

Warranty
Limited Warranty: 1 Year
Additional Warranty Information:

Supermicro provides a three-year warranty for labor and one-year warranty for parts.
